15-pin male DSub connector with 3 standard jacks for RC radios. Plugs in all Roboteq motor controllers equipped with 15-pin connectors: SDC2xxx, MDC1xxx, MDC2xxx, XDC2xxx, SBL1xxx, MBL1xxx.RTQ-CABLE-RC2

Single row ABC Hall Cable and transition board for Brushless Motor Controllers. Includes 6-pin Microfit connector for MBL1xxx, HBL1xxx single-channel controllers and for SBL2xxx, GBL2xxx dual channel controllers. Use two cables for dual channel controllers. Transition board has GND, 5V, A, B C solder pads pads for connecting hall sensors.RTQ-CABLE-ABCX1

12" Cable and transition board for connecting two encoders to Brushed Motor Controllers. Includes 6-pin Microfit connector for MDC2xxx and XDC2xxx dual-channel controllers. Transition board has two sets GND, 5V, A, B solder pads pads for connecting encoders.RTQ-CABLE-ENC1

25-pin male DSub connector with 3 standard jacks for RC radios. Plugs in all Roboteq motor controllers equipped with 25-pin connectors: FBL2xxx, FDC3xxx, FIM2xxx, SBL2xxx, RGBL1xxx, RGBL1xxx, RGDC1xxx, RGIM1xxx, HDC2xxx, HBLxxxxRTQ-CABLE-RC5

ABC Hall Cable and transition board for dual channel Brushless Motor Controllers. Includes dual row 2x5-pin Microfit connector for FBL2xxx, FIM2xxx, HBL2xxx dual channel controllers. Transition board has two sets of GND, 5V, A, B C solder pads pads for connecting hall sensors.RTQ-CABLE-ABCX2

Single row ABC Hall Cable and transition board for Brushless Motor Controllers. Includes 5-pin miniature JST connector for SBL1xxx controllers. Transition board has with GND, 5V, A, B C solder pads pads for connecting hall sensors.RTQ-CABLE-ABCX1M

The USB-232-CONV converter allows the connection of a PC USB port to the RS232 port of a Roboteq controller, allowing the PC communication to the controller in these instances where a direct USB connection is not desired.RTQ-CABLE-USB-232-CONV

9 pin D-Sub cable six feet length male/female9 pin D-Sub cable six feet length male/female.RTQ-CABLE-DS9

Roboteq's MDC2460 controller is designed to convert commands received from an RC radio, Analog Joystick, wireless modem, PC (via RS232 or USB) or microcomputer into high voltage and high current output for driving two DC motors at up to 60V and 60A per channel. Using CAN bus, up to 127 controllers can be networked at up to 1Mbit/s on a single twisted pair.The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms...

Fitting a very compact 70x70mm footprint, Roboteq's SDC2160S controller is designed to convert commands received from an RC radio, Analog Joystick, wireless modem, PC (via RS232 or USB) or microcomputer into high voltage and high current output for driving one DC motor at up to 60V and 40A. Using CAN bus, up to 127 controllers can be networked at up to 1Mbit/s on a single twisted pair.The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform...

Roboteq's FDC3260 is a features-packed, high-current, triple channel controller for brushed DC motors. The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms. The motors may be operated in open or closed loop speed mode, position mode or in torque mode.The FDC3260 features several Analog, Pulse and Digital I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions. The...

Roboteq's MDC1460 controller is designed to convert commands received from an RC radio, Analog Joystick, wireless modem, PC (via RS232 or USB) or microcomputer into high voltage and high current output for driving one DC motor at up to 60V and 120A. Using CAN bus, up to 127 controllers can be networked at up to 1Mbit/s on a single twisted pair.The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms in Open Loop...

Break-out board with 25-pin male DSub connector. Plugs in all Roboteq motor controllers equipped with one 25-pin connectors: FBL2xxx, FDC3xxx, FIM2xxx, SBL2xxx, RGBL1xxx, RGBL1xxx, RGDC1xxx, RGIM1xxx. Brings all of the controller's IO to pads for easy soldering of potentiometers, switches, relays or other accessories. A 9-pin female DSub connectors carries the controller's RS232 signals for direct connection to PC's standard COM port. Use not included 9-pin DSub to 9-pin DSub cable for PC to...

Roboteq's RGBL1860 is a very high-current, features-packed motor controller capable of driving one brushless DC motor up to 60V and 300A. The controller can operate in Trapezoidal mode or Sinusoidal mode with Field Oriented Control (FOC). Several sensors types are supported in order to detect the rotor position and sequence power to the motors' 3 windings in order to generate smooth continuous rotation. The controller can drive sensorless motors in trapezoidal mode.The motor may be operated in...

Roboteq's SDC3260 is a features-packed, high-current, triple channel controller for brushed DC motors. The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms. The motors may be operated in open or closed loop speed mode, position mode or in torque mode. The SDC3260 features several Analog, Pulse and Digital I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions. The...

Roboteq's RGDC1860 is a very high-current, features-packed motor controller for driving one brushed DC motors at up to 60V and 300A. The motor may be operated in open or closed loop speed mode, position mode or in torque mode. The RGDC1860 features an Analog, and several Digital and Pulse I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions. The RGDC1860 accepts commands received from an RC radio, Analog potentiometer, wireless modem, or...

Roboteq's RGIM1860 is a features-packed, very-high-current controller capable of driving one AC Induction motor up to 60V and 300A. The controller can operate in one of several modes in order to sense the rotor position and sequence power on the motors' 3 windings in order to generate smooth continuous rotation. The controller also uses the Encoder information to compute speed and measure traveled distance inside a 32-bit counter. The motors may be operated in open or closed loop speed or...

Break-out board with 15-pin male DSub connector. Plugs in all Roboteq motor controllers equipped with 15-pin connectors: SDC2xxx, MDC1xxx, MDC2xxx, XDC2xxx, SBL1xxx, MBL1xxx. Brings all of the controller's IO to pads for easy soldering of potentiometers, switches, relays or other accessories. A 9-pin female DSub connectors carries the controller's RS232 signals for direct connection to PC's standard COM port. Includes 9-pin DSub to 9-pin DSub cable for connection to a PC. Replaces obsolete RS1...

This product optically isolates the three RS232 lines: Tx, Rx and GND. This will protect your serial devices from transient surges and ground loops up to 5000V in each direction. It is port powered so no external power is necessary.RTQ-RS232-Isolator

This adapter helps to convert TTL (Transistor-Transistor Logic) level signals to RS232 interface of the RoboteQ motor controllers.This converter has a Male DB9 connector, suitable for use with RoboteQ BOB15 and BOB25 break-out boards.Compatible with Arduino, Raspberry Pi, and any other micro controller that uses TTL serial communication.Ultra compact board size: 15 x 14 mm, DB9 Male Connector (RS232), supports 3V to 5.5V power supply, 4 pin through hole: GND, Logic out (TX), Logic In (RX), VCC...

Full speed USB 2.0 compliant port isolator with a 1000V isolation voltage. This device protects your PC or laptop while connecting USB devices wired to high voltages. It is a sealed device with three connectors for connecting with USB-Host, USB-Device and an optional port for an additional power supply (8-15VDC).RTQ-USB-Isolator

Roboteq's MBL1660A is a high-current, features-packed motor controller capable of driving one brushless DC motor up to 60V and 120A. The controller can operate in Trapezoidal mode or Sinusoidal mode with Field Oriented Control (FOC). Several sensors types are supported in order to detect the rotor position and sequence power to the motors' 3 windings in order to generate smooth continuous rotation. The controller can drive sensorless motors in trapezoidal mode.The motor may be operated in open...

DC/DC converter with wide ranging input voltage and fixed 24C outputInput Voltage: DC 37V to 60VOutput Voltage: DC 24VOutput current: 5A. Max 10AAdopts synchronous rectification technology, low heat and high efficiencyAluminum shell, waterproof, shockproofMultiple protection function: output over-current protection, soft-start protection, chip over-temperature protection (No reversal protection, do NOT reverse)Working temperature: -40 °c ~ +85 °c (industrial temperature)Efficient...

Roboteq's KBL1660 is a rugged, high-current, features-packed motor controller capable of driving one brushless DC motor up to 60V and 120A. The controller can operate in Trapezoidal mode or Sinusoidal mode with Field Oriented Control (FOC). Several sensors types are supported in order to detect the rotor position and sequence power to the motors' 3 windings in order to generate smooth continuous rotation. The controller can drive sensorless motors in trapezoidal mode.The motor may be operated...
